RNB Series Non-Insulated Ring Terminal Pure Red Copper Bare Cold Crimp Lug
| Item | Specification |
|---|---|
| Product Series | RNB Series Non-Insulated Ring Terminal |
| Material | High purity red copper, tin plated |
| Certification | CE, RoHS, TUV, UL, REACH |
| Rated Voltage | 600V |
| Temperature Range | -40°C ~ 125°C |
| Type | Bare / Non-insulated Round Ring Cold Crimp Terminal |
| Wire Range | 0.5mm² – 25mm² |
| Feature | No insulation, seamless stamping, high current bearing, easy crimping |
| Application | Electrical cabinet, power distribution, grounding, industrial equipment, automotive wiring |
RNB Series Pure Red Copper Non-insulated Ring Terminal, Bare Round Cold Crimp Wire Lug
Installation Diagram & Step Instruction
Step-by-Step Installation Diagram
Standard crimping steps for RNB non-insulated ring terminal. Professional operation ensures tight crimping and reliable electrical connection.
Strip appropriate wire insulation to expose complete copper core.
Insert the wire into the bare terminal barrel fully.
Crimp firmly with dedicated cold crimping pliers.
Fasten the ring terminal on the bolt with screw tightening.
